Summary

Use this skill when working with RenderDoc capture files (.rdc), analyzing GPU frames, tracing shaders, inspecting draw calls, or running CI assertions against GPU captures. Trigger phrases: "open capture", "rdc file", ".rdc", "renderdoc", "shader debug", "pixel trace", "draw cal

Files · 1

View on GitHub

SKILL.md

1	# rdc-cli Skill
2
3	## Overview
4
5	rdc-cli is a Unix-friendly command-line interface for RenderDoc GPU captures. It provides a daemon-backed architecture using JSON-RPC over TCP, a virtual filesystem (VFS) path namespace for navigating capture internals, and composable commands designed for shell pipelines, scripting, and CI assertions.
6
7	Install: `pip install rdc-cli` (requires a local RenderDoc build with Python bindings).
8	Check setup: `rdc doctor`.
9
10	## Core Workflow
11
12	Follow this session lifecycle for any capture analysis task:
13
14	1. Open a capture:
15	- Local: `rdc open path/to/capture.rdc`
16	- Remote replay (Proxy): `rdc open capture.rdc --proxy host:port`
17	- Split thin-client: `rdc open --connect host:port --token TOKEN`
18	- Android device: `rdc open capture.rdc --android [--serial SERIAL]`
19	2. Inspect metadata: `rdc info`, `rdc stats`, `rdc events`
20	3. Navigate the VFS: `rdc ls /`, `rdc ls /textures`, `rdc cat /draws/0/pipeline/summary`
21	4. Analyze specifics: `rdc shaders`, `rdc pipeline`, `rdc resources`, `rdc bindings`
22	5. Debug shaders: `rdc debug pixel EID X Y`, `rdc debug vertex EID VTXID`, `rdc debug thread EID GX GY GZ`
23	6. Export data: `rdc texture ID -o out.png`, `rdc rt EID`, `rdc buffer ID -o buf.bin`, `rdc cbuffer EID --stage ps --binding 0`, `rdc log`
24	7. Close the session: `rdc close`
25
26	### Session Management
27
28	- Default session name: `default` (or value of `$RDC_SESSION`).
29	- Override per-command: `rdc --session myname open capture.rdc`.
30	- Check active session: `rdc status`.
31	- Navigate to a specific event: `rdc goto EID`.
32
33	## Output Formats
34
35	All list/table commands default to TSV (tab-separated values) with a header row, suitable for `cut`, `awk`, and `sort`.
36
37	\| Flag \| Format \| Use Case \|
38	\|------\|--------\|----------\|
39	\| (default) \| TSV with header \| Human reading, shell pipelines \|
40	\| `--no-header` \| TSV without header \| Piping to `awk`/`cut` without stripping \|
41	\| `--json` \| JSON array \| Structured processing with `jq` \|
42	\| `--jsonl` \| Newline-delimited JSON \| Streaming processing, large datasets \|
43	\| `-q` / `--quiet` \| Minimal (single column) \| Extracting IDs for loops \|
44
45	Example -- get all draw call EIDs as a plain list:
46
47	```bash
48	rdc draws -q
49	```
50
51	Example -- JSON pipeline with jq:
52
53	```bash
54	rdc events --json \| jq '.[] \| select(.type == "DrawIndexed")'
55	```
56
57	## Render Pass Analysis
58
59	### List passes (Phase 8 columns)
60
61	`rdc passes` outputs 6 columns: NAME, DRAWS, DISPATCHES, TRIANGLES, BEGIN_EID, END_EID.
62
63	```bash
64	rdc passes # TSV table
65	rdc passes --json # includes load_ops/store_ops per pass
66	rdc passes --deps --table # per-pass READS/WRITES/LOAD/STORE
67	```
68
69	### Inspect a single pass
70
71	`rdc pass <name>` shows enriched attachments: resource name, format, dimensions, and load/store ops.
72
73	```bash
74	rdc pass GBuffer
75	rdc pass GBuffer --json
76	rdc pass 0 # by 0-based index
77	```
78
79	### Detect dead render targets
80
81	`rdc unused-targets` finds render targets written but never consumed by visible output. Columns: ID, NAME, WRITTEN_BY, WAVE.
82
83	```bash
84	rdc unused-targets # TSV
85	rdc unused-targets --json # structured
86	rdc unused-targets -q # one resource ID per line (for scripting)
87	```
88
89	### Frame statistics
90
91	`rdc stats` outputs three sections: Per-Pass Breakdown, Top Draws by Triangle Count, and Largest Resources.
92
93	```bash
94	rdc stats # all three sections
95	rdc stats --json # includes largest_resources array
96	```
97
98	GL/GLES/D3D11 captures without native BeginPass/EndPass markers get synthetic pass inference automatically — no extra flags needed.
99
100	## Common Tasks
101
102	### Find all draw calls
103
104	```bash
105	rdc draws
106	rdc draws --pass "GBuffer" --json
107	```
108
109	### Trace a pixel
110
111	```bash
112	rdc debug pixel 1024 512 384 # EID first, then X Y
113	rdc debug pixel 1024 512 384 --json # structured output
114	rdc debug pixel 1024 512 384 --trace # full step-by-step trace
115	```
116
117	### Search shaders by name or source
118
119	```bash
120	rdc search "main" # regex search over shader disassembly
121	rdc search "Sample" --stage ps -C 2
122	rdc shaders --name "GBuffer*"
123	```
124
125	### Export render targets
126
127	```bash
128	rdc rt EID -o output.png
129	rdc rt EID --depth -o depth.png # export the raw depth attachment
130	rdc texture ID -o tex.png # export a texture by resource ID (PNG)
131	```
132
133	### Decode a constant buffer
134
135	```bash
136	rdc cbuffer EID --stage ps --binding 0 # decode to JSON
137	rdc cbuffer EID --stage vs --binding 0 --raw -o cbuffer.bin
138	```
139
140	### Browse VFS paths
141
142	```bash
143	rdc ls /
144	rdc ls /textu
