delphi-uses-graph

Name: delphi-uses-graph
Author: MaxiDonkey

59stars12forks

How to install delphi-uses-graph?

maxidonkey/delphianthropic/delphi-uses-graph

$npx -y skills add MaxiDonkey/DelphiAnthropic --skill delphi-uses-graph

Installs into the current project.

Summary

Analyzes a Delphi / Object Pascal codebase to extract unit-level uses dependencies. Use when the user uploads a zip / archive of a Delphi project (or a folder of .pas / .dpr / .dpk files) and asks for a dependency graph, architecture map, cycle detection, fan-in / fan-out coupl

Files · 1

View on GitHub

SKILL.md

1	# Delphi uses-graph skill
2
3	This skill builds a directed graph of `uses` dependencies between Delphi /
4	Object Pascal units, computes coupling metrics, and detects circular
5	dependencies.
6
7	## When to use this skill
8
9	- The user uploads an archive (`.zip`, `.tar`, `.tar.gz`) containing a Delphi
10	project, or a folder of `.pas` / `.dpr` / `.dpk` sources, and asks for an
11	architecture map or a dependency graph.
12	- The user asks "which unit depends on what?", "are there cycles?",
13	"what's the fan-in / fan-out?" against a Delphi codebase.
14	- The user wants a visual artifact (Mermaid embed, SVG, DOT) summarizing
15	unit-level coupling.
16
17	Do not use this skill for non-Pascal codebases.
18
19	## Inputs
20
21	The skill expects exactly one of:
22
23	1. A `.zip` / `.tar` / `.tar.gz` archive of a Delphi project (preferred).
24	2. A directory already containing `.pas`, `.dpr`, `.dpk` files.
25
26	If the user pastes raw Pascal source instead, persist it to one or more
27	temporary `.pas` files first, then point `--input` at their parent directory.
28
29	## Workflow
30
31	1. Locate the input archive or directory in the working area.
32	2. Run `scripts/tool.py` with `--input` pointing at it and `--output`
33	pointing at a fresh subfolder of the working area.
34	3. Read the generated `report.md` and summarize findings to the user:
35	number of parsed units, top fan-in / fan-out, cycles, orphan units.
36	4. Attach the produced artifacts (Mermaid, DOT, SVG when present, JSON,
37	report) to the response. Embed `uses-graph.mmd` inline in the answer so
38	the user sees the diagram rendered.
39
40	## Quick start
41
42	```bash
43	python scripts/tool.py \
44	--input /path/to/project.zip \
45	--output /path/to/out
46	```
47
48	Useful flags (full list in `reference.md`):
49
50	- `--scope {all,interface,implementation}` — which `uses` sections to
51	consider. Default `all`.
52	- `--ignore-prefix LIST` — drop edges whose target starts with one of these
53	comma-separated prefixes, case-insensitive. Default
54	`System,Winapi,Vcl,FMX,Data,Web,REST,IdGlobal`. Pass `""` to keep RTL/VCL.
55	- `--max-label N` — truncate node labels in the Mermaid output (default 40).
56	- `--include-orphans` — keep units that have no inbound and no outbound
57	edges in the graph.
58
59	## Outputs (in `--output`)
60
61	\| File \| Purpose \|
62	\| ------------------- \| ---------------------------------------------------------------------------------------- \|
63	\| `dependencies.json` \| Raw graph: `{ unit: { defined_in, interface_uses, implementation_uses } }` \|
64	\| `uses-graph.mmd` \| Mermaid `graph LR` ready to embed in a markdown answer \|
65	\| `uses-graph.dot` \| Graphviz DOT source \|
66	\| `uses-graph.svg` \| SVG rendering — only when the `dot` binary is available on `PATH` \|
67	\| `report.md` \| Human-readable summary: counts, top hotspots, cycles, orphans \|
68
69	## Notes
70
71	- RTL / VCL / FMX targets are filtered by default to keep the diagram
72	readable. The user's own units are never filtered.
73	- Cycle detection uses Tarjan's strongly connected components on the
74	directed graph (edge `A -> B` means A uses B). Self-loops are reported
75	separately.
76	- Pascal `uses` syntax has several edge cases (dotted names, `in '<path>'`
77	aliases, conditional defines, three comment styles). Read `reference.md`
78	before changing the parser.
