delphi-uses-graph

Name: delphi-uses-graph
Author: MaxiDonkey

87stars20forks

How to install delphi-uses-graph?

maxidonkey/delphigenai/delphi-uses-graph

$npx -y skills add MaxiDonkey/DelphiGenAI --skill delphi-uses-graph

Installs into the current project.

Summary

Analyzes a Delphi / Object Pascal codebase to extract unit-level uses dependencies. Use when the user uploads a zip / archive of a Delphi project, or a folder of .pas / .dpr / .dpk files, and asks for a dependency graph, architecture map, cycle detection, fan-in / fan-out coupl

Files · 1

View on GitHub

SKILL.md

1	# Delphi uses-graph skill
2
3	This skill builds a directed graph of `uses` dependencies between Delphi /
4	Object Pascal units, computes coupling metrics, and detects circular
5	dependencies.
6
7	## OpenAI Responses container note
8
9	This OpenAI-adapted bundle is intended to be registered through the OpenAI
10	Skills API and attached to a Responses shell/container tool as a
11	`skill_reference`. The analysis logic is vendor-neutral; the OpenAI-specific
12	requirement is that the container can run Python and can read the uploaded
13	Delphi project files.
14
15	## When to use this skill
16
17	- The user uploads an archive (`.zip`, `.tar`, `.tar.gz`) containing a Delphi
18	project, or a folder of `.pas` / `.dpr` / `.dpk` sources, and asks for an
19	architecture map or a dependency graph.
20	- The user asks "which unit depends on what?", "are there cycles?",
21	"what's the fan-in / fan-out?" against a Delphi codebase.
22	- The user wants a visual artifact (Mermaid, SVG, DOT) summarizing unit-level
23	coupling.
24
25	Do not use this skill for non-Pascal codebases.
26
27	## Inputs
28
29	The skill expects exactly one of:
30
31	1. A `.zip` / `.tar` / `.tar.gz` archive of a Delphi project.
32	2. A directory already containing `.pas`, `.dpr`, or `.dpk` files.
33
34	If the user pastes raw Pascal source instead, persist it to one or more
35	temporary `.pas` files first, then point `--input` at their parent directory.
36
37	## Workflow
38
39	1. Locate the input archive or directory in the working area.
40	2. Run `scripts/tool.py` with `--input` pointing at it and `--output` pointing
41	at a fresh output folder.
42	3. Read the generated `report.md` and summarize parsed units, fan-in/fan-out,
43	cycles, and orphan units.
44	4. Attach or surface the generated artifacts: Mermaid, DOT, SVG when present,
45	JSON, and report. Embed `uses-graph.mmd` inline when the conversation
46	surface supports Mermaid rendering.
47
48	## Quick start
49
50	```bash
51	python scripts/tool.py \
52	--input /path/to/project.zip \
53	--output /path/to/out
54	```
55
56	If the container exposes `python3` instead of `python`, use `python3` with the
57	same arguments.
58
59	Useful flags, with full details in `reference.md`:
60
61	- `--scope {all,interface,implementation}` - which `uses` sections to
62	consider. Default `all`.
63	- `--ignore-prefix LIST` - drop edges whose target starts with one of these
64	comma-separated prefixes, case-insensitive. Default:
65	`System,Winapi,Vcl,FMX,Data,Web,REST,IdGlobal`. Pass `""` to keep RTL/VCL.
66	- `--max-label N` - truncate node labels in the Mermaid output. Default `40`.
67	- `--include-orphans` - keep units that have no inbound and no outbound edges
68	in the graph.
69
70	## Outputs
71
72	Files written in `--output`:
73
74	\| File \| Purpose \|
75	\| --- \| --- \|
76	\| `dependencies.json` \| Raw graph: `{ unit: { defined_in, interface_uses, implementation_uses } }` \|
77	\| `uses-graph.mmd` \| Mermaid `graph LR` ready to embed in markdown \|
78	\| `uses-graph.dot` \| Graphviz DOT source \|
79	\| `uses-graph.svg` \| SVG rendering, only when the `dot` binary is available on `PATH` \|
80	\| `report.md` \| Human-readable summary: counts, hotspots, cycles, orphans \|
81
82	## Notes
83
84	- RTL / VCL / FMX targets are filtered by default to keep the diagram readable.
85	The user's own units are never filtered.
86	- Cycle detection uses Tarjan's strongly connected components on the directed
87	graph. Edge `A -> B` means `A uses B`. Self-loops are reported separately.
88	- Pascal `uses` syntax has several edge cases: dotted names, `in '<path>'`
89	aliases, conditional defines, and three comment styles. Read `reference.md`
90	before changing the parser.
