ue5-blueprint-workflow

Name: ue5-blueprint-workflow
Author: teixasalone

16stars3forks

How to install ue5-blueprint-workflow?

teixasalone/unrealengine5-skills/ue5-blueprint-workflow

$npx -y skills add teixasalone/UnrealEngine5-Skills --skill ue5-blueprint-workflow

Installs into the current project.

Summary

UE5.6/UE5.7 Blueprint graph workflow for feature implementation, input events, node wiring, and graph validation. Use when requests involve adding Blueprint logic, keyboard input behavior, function chains, event graph edits, or pin-level connection guidance.

Files · 1

View on GitHub

SKILL.md

1	# Quick Start
2	- Identify target Blueprint asset and graph (`EventGraph` or function graph).
3	- Confirm requested behavior as event -> logic -> output chain.
4	- Decide input route first: legacy key event or Enhanced Input action event.
5	- Produce graph-level steps first, then exact node/pin wiring details.
6
7	# UE5.7 API Anchors
8	- Keyboard and event node anchors:
9	- `UK2Node_InputKey`, `UK2Node_InputAction`, `UK2Node_InputActionEvent`
10	- `UK2Node_CallFunction`, `UK2Node_CustomEvent`
11	- Enhanced Input anchors:
12	- `UInputAction`, `UInputMappingContext`
13	- `UEnhancedInputLocalPlayerSubsystem::AddMappingContext(...)`
14	- `UEnhancedInputLocalPlayerSubsystem::RemoveMappingContext(...)`
15	- `UEnhancedInputComponent::BindAction(...)`
16	- Tool fast-path anchors (preferred for Blueprint editing automation):
17	- `blueprint_modify` with `operation=add_input_key_event`
18	- `blueprint_modify` with `operation=connect_pins`
19	- `blueprint_query` for pin inspection and compile checks
20
21	# Graph Stage Contract
22	- Every requested Blueprint feature must specify:
23	- Entry event source (key/input action/custom event)
24	- Core logic nodes (minimum two meaningful nodes)
25	- Required pin-level connections (exec and data pins)
26	- Output/side effects (state change, call, spawn, UI)
27	- Validation method (compile status, node/pin inspection, expected execution order)
28	- If any item is missing, the graph implementation is incomplete.
29
30	# Workflow
31	## 1) Entry Event
32	- Keyboard requests: use `add_input_key_event` first with `reuse_existing=true`.
33	- Enhanced Input requests: add/reuse Input Action event nodes (`UK2Node_InputActionEvent` path).
34	- Do not perform generic event-node guessing before trying dedicated input operations.
35
36	## 2) Core Logic Chain
37	- Build minimal deterministic logic with explicit control flow (`Branch`, `Sequence`, function calls).
38	- Prefer existing graph variables/functions over creating redundant nodes.
39	- Keep one clear execution path per behavior branch.
40
41	## 3) Pin Wiring
42	- Connect exec pins before data pins to lock execution order.
43	- Inspect exact pin names via `blueprint_query` before `connect_pins`.
44	- Avoid ambiguous autowiring when multiple overload pins exist.
45
46	## 4) State/Output
47	- Apply state updates (variables/tags), then side effects (spawn/call/UI feedback).
48	- Keep output nodes isolated by intent to simplify later debugging.
49	- When both success/fail paths exist, wire both explicitly.
50
51	## 5) Validation and Summary
52	- Validate compile state and pin integrity after wiring.
53	- Confirm there are no duplicate input nodes for the same key/action.
54	- Summarize final chain in deterministic order: entry -> branch -> action -> output.
55
56	# Constraints
57	- Mandatory hotkey rule: use `add_input_key_event` first for keyboard features.
58	- Keep `reuse_existing=true` for key events to avoid duplicates.
59	- Avoid trial-and-error node class guessing when a dedicated operation exists.
60	- Separate graph steps from pin-level detail in final output.
61	- Prefer Enhanced Input assets (`UInputAction`/`UInputMappingContext`) for new input systems.
62	- Avoid hidden behavior in latent/timer nodes unless explicitly requested.
63
64	# Failure Handling
65	- Symptom: key press does not fire.
66	- Locate: input node type, duplicated key nodes, input focus/context.
67	- Fix: reuse/create via `add_input_key_event`, remove duplicates, verify mapping context path.
68	- Symptom: graph compiles with warnings but behavior is wrong.
69	- Locate: branch conditions and exec pin order.
70	- Fix: reorder exec chain and verify condition data pins.
71	- Symptom: pin connection fails in automation.
72	- Locate: node variant pin names or overload mismatch.
73	- Fix: run `blueprint_query` to inspect exact pins before wiring.
74	- Symptom: Enhanced Input event exists but never triggers.
75	- Locate: mapping context registration and action binding path.
76	- Fix: ensure mapping context is added and action event node matches action asset.
77	- Symptom: event fires multiple times unexpectedly.
78	- Locate: duplicate entry nodes or repeated binding paths.
79	- Fix: consolidate to one entry node and guard re-entrant path with state flags.
80	- Symptom: graph no longer compiles after edits.
81	- Locate: broken links after node replacement or stale function signatures.
82	- Fix: reconnect required pins and refresh function node signatures.
83
84	# UE5.6 / UE5.7 Compatibility Notes
85	- Core Blueprint graph nodes above are stable across UE5.6 and UE5.7.
86	- Prefer Enhanced Input path for new implementations in both versions.
87
88	# Escalation
89	- Escalate when behavior requires C++ extension, custom latent nodes, or engine plugin changes.
90	- Escalate when Blueprint is locked, corrupted, or cannot compile due to unrelated project errors
