node-red

Name: node-red
Author: tonylofgren

83installs3forks

How to install node-red?

tonylofgren/aurora-smart-home/node-red

$npx -y skills add tonylofgren/aurora-smart-home --skill node-red

Installs into the current project.

Summary

Node-RED visual automation flows for Home Assistant. Covers visual automation, flow JSON, trigger-state, api-call-service, function nodes, context storage, timer patterns, error handling, and node-red-contrib-home-assistant-websocket nodes. Use when user mentions "Node-RED", "flo

Files · 1

View on GitHub

SKILL.md

1	# Node-RED for Home Assistant
2
3	Build Node-RED flows using node-red-contrib-home-assistant-websocket nodes (v0.80+).
4
5	Requirements: Node-RED 4.x (Node.js 18+), Home Assistant 2024.3.0+.
6
7	## The Iron Law
8
9	```
10	USE CURRENT NODE NAMES - NEVER OUTDATED ONES
11	```
12
13	The node-red-contrib-home-assistant-websocket package has renamed several nodes. Using old names produces broken flows that silently fail.
14
15	## Delivery Contract (read first, applies to every output)
16
17	Every flow ships as files in a project folder on disk. Chat output is not delivery. A flow JSON pasted in chat is not a delivered flow. Create `<project-slug>/` (or write into the existing project folder in a multi-agent build), write the flow JSON under `node-red-flows/`, and write a `README.md` per Iron Law 3 in `../aurora/souls/river.md`. README sections follow `../aurora/references/deliverables/manual-format.md`: What this does, Installation, Troubleshooting, Recovery. No chat-only output option.
18
19	## The Process
20
21	```
22	User request
23	│
24	▼
25	HA server config node exists in Node-RED?
26	│ no ─────────────────────────┐
27	│ yes ▼
28	│ Set up `server` config first
29	│ (URL, access token, allow self-signed if needed)
30	│ │
31	▼ ◀────────────────────────────┘
32	Pick trigger node (current names only — see table below)
33	│
34	│ time-based? ──▶ inject (time) or trigger-state with cron
35	│ state-change? ──▶ trigger-state OR events:state
36	│ event? ──▶ events:all (filtered by event_type)
37	│ external? ──▶ http in (webhook) / mqtt in
38	│
39	▼
40	Add filter/condition (current-state, switch, template)
41	│
42	▼
43	Pick action node (current names only)
44	│
45	│ call HA service? ──▶ call-service (`action`, not `service`)
46	│ set entity state? ──▶ call-service light.turn_on / etc.
47	│ send HTTP? ──▶ http request
48	│ notify? ──▶ call-service notify.*
49	│
50	▼
51	Battery-drain risk? ──yes──▶ Add throttle/delay (rate-limit msgs/sec)
52	│ no
53	▼
54	Add status indicators (debug node OR catch node for error path)
55	│
56	▼
57	Test in editor with debug node, fix wiring
58	│
59	▼
60	Deploy and verify in HA
61	│
62	▼
63	Document the flow (description on key nodes)
64	```
65
66	## Critical: Node Names Have Changed
67
68	STOP. If you're about to use any of these node types, you're using outdated names:
69
70	\| WRONG (Old) \| CORRECT (Current) \|
71	\|-------------\|-------------------\|
72	\| `server-state-changed` \| `trigger-state` or `events:state` \|
73	\| `poll-state` \| `poll-state` (unchanged but check config) \|
74	\| `call-service` \| `api-call-service` \|
75
76	## Trigger Node Configuration (Current API)
77
78	```json
79	{
80	"type": "trigger-state",
81	"entityId": "binary_sensor.motion",
82	"entityIdType": "exact",
83	"constraints": [
84	{
85	"targetType": "this_entity",
86	"propertyType": "current_state",
87	"comparatorType": "is",
88	"comparatorValue": "on"
89	}
90	],
91	"outputs": 2
92	}
93	```
94
95	entityIdType options: `exact`, `substring`, `regex`
96
97	There is NO `list` type. To monitor multiple entities, use `regex`:
98	```json
99	"entityId": "binary_sensor\\.motion_(1\|2\|3)",
100	"entityIdType": "regex"
101	```
102
103	## Service Call Configuration (Current API)
104
105	```json
106	{
107	"type": "api-call-service",
108	"domain": "light",
109	"service": "turn_on",
110	"entityId": ["light.living_room"],
111	"data": "",
112	"dataType": "json"
113	}
114	```
115
116	Or dynamic via msg:
117	```json
118	{
119	"type": "api-call-service",
120	"domain": "",
121	"service": "",
122	"data": "",
123	"dataType": "msg"
124	}
125	```
126
127	With function node before:
128	```javascript
129	msg.payload = {
130	action: "light.turn_on",
131	target: { entity_id: ["light.living_room"] },
132	data: { brightness_pct: 80 }
133	};
134	return msg;
135	```
136
137	## Current State Node - Single Entity Only
138
139	`api-current-state` queries ONE entity, not patterns.
140
141	```json
142	{
143	"type": "api-current-state",
144	"entity_id": "person.john"
145	}
146	```
147
148	To check multiple entities, use function node:
149	```javascript
150	const ha = global.get("homeassistant").homeAssistant.states;
151	const people = Object.keys(ha)
152	.filter(id => id.startsWith("person."))
153	.filter(id => ha[id].state !== "home");
154	msg.awayPeople = people;
155	return msg;
156	```
157
158	## Entity Nodes Require Extra Integration
159
160	The following nodes require `hass-node-red` integration (separate from the websocket nodes):
161	- `ha-entity` (sensor, binary_sensor, switch, etc.)
162	- Entity config nodes
163
164	Always mention this prerequisite when using entity nodes.
165
166	## Stable Entity Nodes (v0.71.0+)
167
168	These nodes were promoted from beta to s
