drawio-mcp-server

Name: drawio-mcp-server
Author: simonkurtz-MSFT

77stars15forks

How to install drawio-mcp-server?

simonkurtz-msft/drawio-mcp-server

$git clone https://github.com/simonkurtz-MSFT/drawio-mcp-server

Installs into the current project.

Summary

A Model Context Protocol (MCP) server for programmatic diagram generation using Draw.io (Diagrams.net). This server generates Draw.io XML directly — no browser extension or Draw.io instance required.
