threejs-camera-direction

Name: threejs-camera-direction
Author: scottstts

377stars47forks

How to install threejs-camera-direction?

scottstts/threejs-awesome-graphics-agent-skills/threejs-camera-direction

$npx -y skills add scottstts/Threejs-Awesome-Graphics-Agent-Skills --skill threejs-camera-direction

Installs into the current project.

Summary

Direct advanced Three.js camera systems. Use for scale-aware chase rigs, thrust lag, side/orbit cameras, body-relative up vectors, quaternion handoffs, authored cinematic framing, floating origins, pointer-look controls, camera collision constraints, projection ownership, and lif

Files · 1

View on GitHub

SKILL.md

1	# Camera Direction
2
3	Treat the camera as an authored visual system, not a passive viewport. Compose
4	the subject, establish scale, choose a stable up frame, and make every mode
5	handoff explicit.
6
7	## Build order
8
9	1. Define the design frame: subject size, screen occupancy, lens, near/far,
10	motion, and horizon/up convention.
11	2. Build camera targets in semantic frames: ship, body surface, docking axis,
12	or scene-authored shot.
13	3. Derive position and orientation independently, then combine them once.
14	4. Add input orbit/look only inside declared yaw/pitch and spatial constraints.
15	5. Add frame-rate-independent follow or a bounded spring where the reference
16	uses inertia.
17	6. Snapshot and restore camera projection/state when a scene owns it.
18	7. Test mode transitions, cuts, pointer-lock reacquisition, resize, and large
19	coordinates.
20
21	Read [references/camera-rig-and-cinematic-systems.md](references/camera-rig-and-cinematic-systems.md)
22	for exact chase/side/orbit rigs, projection values, transition
23	rules, floating-origin shot, pointer controls, and implementation limits.
24
25	## Non-negotiable rules
26
27	- Use subject dimensions to derive offsets; do not tune one fixed distance for
28	differently scaled assets.
29	- For planetary motion, derive up from the dominant body rather than global Y.
30	- Interpolate position with `lerp` and orientation with `slerp`.
31	- During an explicit handoff, use one interpolation stage. Do not stack a
32	transition blend and a second follow smoother over the same interval.
33	- Re-sync yaw/pitch from the camera when pointer lock is acquired.
34	- Update the projection matrix whenever FOV, near, far, or aspect changes.
35	- Keep stars or infinite backgrounds camera-relative when large translation
36	would create false parallax or precision loss.
37	- Restore camera and input ownership on scene disposal.
38
39	## Routing boundary
40
41	Use `$threejs-procedural-animation` for object motion timelines, springs,
42	docking, staging, and debris. This skill owns how the scene is viewed and how
43	camera modes hand off.
